If a code and the abbreviation PB are marked on the key, the keys were supplied together with a coded property card, as it is a protected key profile with controlled duplication, which is only possible at the Viro factory. In this case, the duplication request must be made by going to a Viro product dealer or an Authorized Service Centre and presenting an original key and the ownership card (or at least the property card if all the keys have been lost). The dealer or the Service Centre will pass the request to Viro who will make the duplications. If, however, the safe has an emergency key which does not show any markings and does not have an ownership card, you must contact our Technical Assistance at Freephone number 800136005 (calling from a landline) on the days and times indicated on the website.

Spare parts cannot be purchased directly from Viro, but only through our authorised dealers, which can be identified here.

It is not possible to build the case of the security cabinets into a wall as these products are not designed for this type of fixing; they are to be anchored to the wall or floor with plugs.

The use of a double coil on Viro electric locks (rather than a single coil) guarantees greater reliability over time and a better operation of the product.

It is indifferent, since the treatment which makes the lock resistant to corrosion (caused by atmospheric agents, humidity, etc.) is that of galvanizing, which is always present in Viro electric locks, even in those whose casing is subsequently painted.

.

In this case it is necessary to contact the Viro Technical Assistance at Freephone number 800136005 (calling from a landline) on the days and times indicated on the website.

To get a new master key for Hotel safes you need to contact Viro directly, asking for the Hotel Division.

In this case it is necessary to contact Viro directly, asking for the Hotel Division.

The lock of the armoured cabinet item 4483.T is certified according to UNI EN 1300. The steels used for construction of the cases of all Viro cabinets meet the UNI EN 10130 standard (the steels used for the item 4483.T meet standard UNI EN 10139).

Simply contact a Viro dealer (who can be identified through the retailer search on the website) and order the product with the desired voltage.

Simply contact a Viro dealer (who can be identified through the retailer search on the website) and order the product with the desired voltage.

To determine the correct voltage necessary to power the electrical striker, it is necessary to contact a specialized electrician who, using a voltmeter, measures the voltage at the ends of the connection wires

Yes, it is possible to order a spare cylinder without armour (item 4717) for the lock item 8217

Yes, it is possible to install the armoured lock item 8271 vertically, checking that the weight of the lock-bolts does not compromise operation.

The double-edged latch ensures a good seal whilst making it easier to install the lock, as it has characteristics for self-centring on the striker plate.

The protrusion of the cylinder from the outside must be at least 6 mm. and at most 11 mm.

It is necessary to consult the specific table called “Selection and installation of the cylinder" contained in the installation instructions supplied with the product, which can also be downloaded on the product web page.

As indicated in the installation instructions, the trapezoidal fixing base placed at the end of the arm in the "less force" position must be rotated, using the same fixing holes, following the instructions provided with the product, which can also be downloaded from the product web page.

You can make 2 overlapping holes using a 20 mm cup wheel cutter.

Van Lock is generally applicable on the vast majority of transport vehicles, but the models are periodically renewed, depending on the innovations launched by the manufacturers. The Viro Technical Office regularly carries out compatibility checks, so, to know whether your new vehicle has already been checked, contact the Viro Technical Assistance at Freephone number 800136005 (calling from a landline) on the days and times indicated on the website.

It is not possible because once the customer has set up a personal code the lock will only open with that code.

Yes, in fact, even the rivets are supplied.

If AA alkaline batteries are used, the duration of the batteries is approximately 6 months, considering a normal daily use of the device, which envisages keeping it off during movement and activated when the vehicle is parked.

Although there is no legal requirement, in order to offer a high level of service, Viro tends to guarantee the availability of spare parts relating to products for at least for 2 years after the products are no longer actually in production. To find out if a product is still in production, just check whether it is on the website.

.

In this case it is necessary to contact Viro directly, asking for the Hotel Division.

To obtain hotel safe user manuals, contact Viro directly, asking for the Hotel Division.

In this case it is necessary to contact the Viro Technical Assistance at Freephone number 800136005 (calling from a landline) on the days and times indicated on the website.

In order to guarantee the correct operation of the product, it is not possible to install the cabinet upside down.

Depending on the model, the Viro locks are compatible for replacing most of the electric locks (of the Italian type) already installed.

No, because Viro electrical strikers are designed for home or office use, whilst those for hotel use meet different regulations and certifications.

It is not advisable to use electrical strikers in environments with high atmospheric aggressiveness since the compartment containing the electrical part is not watertight.

It is not possible to replace the armoured lock cylinder for up and over doors item 8217 with a European profile cylinder, as the original one is an integrated armoured cylinder. If you want to have a European profile cylinder with locks for up and over doors, you must opt for the Viro series 1.8234 and 1.8252 multi-point armoured locks, which are compatible with most of the locks on the market.

Yes, it is possible to also install the armoured lock item 8271 on wooden doors, with a maximum thickness of 40 mm, so that the screws supplied can be used.

Viro mortise locks are designed to work correctly with cylinders with either a DIN cam or a universal cam.

The protrusion of the cylinder from the inside must be at least 9 mm.

No need for maintenance, it is not necessary to top up the oil, which is actually contained in a sealed compartment, which is why the closing speed and final stroke control valves must never be completely unscrewed. Depending on the outside temperature, it is sufficient to slightly act on the valves, by tightening or loosening them to obtain changes to the closing speed of the door closer.

The life of the batteries is variable (from a few months to more than a year) depending on the frequency and conditions of use. Every time it is activated the electronic Spranga locking bar checks the state of charge of the batteries, if necessary alerting, with acoustic signals and with a text message, the need to replace them.

The simple operations to shorten the Spranga locking bar are shown at this point in the installation video

The TSA key is only available, for obvious security reasons, to the competent authorities and cannot therefore be provided.

Once the M.A.S. detects the break-in attempt, the alarm procedure begins. The module takes about 6 seconds to send both the attempted break-in message and the text with the coordinates of the position from which it is moved. Subsequently, if it continues to detect movements, it sends 3 intermediate text messages at about 10 minutes from each other (each send depends on the vibrations suffered).
Once the module has stopped (it does not detect vibrations), it sends the "stopped” text message after abut 4 seconds.

It is not possible to use rechargeable batteries, as the voltage required for the correct operation of our safes is not compatible with these type of batteries.

.

For security reasons, if the Master Code has already been customized and correctly entered (and, therefore, it is no longer the factory one) it is not possible to recover it. If it is still the factory one and the relative manual has been lost, you can contact Viro directly, asking for the Hotel Division.

In this case it is necessary to contact the Viro Technical Assistance at Freephone number 800136005 (calling from a landline) on the days and times indicated on the website.

Yes, it is possible to buy and connect the rectifier bridge (item 7911) which eliminates the vibrations, making the lock quieter.

On the Viro security locks for up and over doors (item 8217 with integrated protected cylinder and the multi-point armour series 1.8234 and 1.8252 where the profile cylinder can be protected by a security escutcheon with anti-drill rotating plate item 806) it is possible to add the inner protection plate (item 1.4234.0465) made of cut-resistant and anti-drill, casehardened and tempered steel, which protects the lock unit, thus creating a complete kit which is able to counteract break-in attempts to a maximum extent.

It is not possible because the lock item 8271 is already supplied with a specific security escutcheon which does not have holes.

For application of this type of security escutcheon, the presence is required on the lock case of DIN through holes. If the lock is not equipped with it, use of the security escutcheon item 809 is suggested, which is also suitable for locks without DIN holes.

The maximum thickness of the door, for using the screws supplied, is 70 mm.

It must be simply of the GSM type

It is not advisable to use a cylinder equipped with a knob on the inside with the Spranger locking bar installed vertically, since the lock mechanism may not work properly.

The Van Lock can be easily installed privately or through car body shops, following the installation instructions supplied with the product, which can also be downloaded (together with the video) on the product web page.

Yes, to exit if you accidentally get locked inside the loading compartment, the emergency release must be on at least one of the two doors.

Remote interrogation of the module is not planned.

The page where you can download the user manuals of the safes no longer in the range can be reached by clicking here.

.

Although there is no legal requirement, in order to offer a high level of service, Viro tends to guarantee the availability of spare parts relating to products for at least for 2 years after the products are no longer actually in production. To find out if a product is still in production, just check whether it is on the website.

Additional holes can be made, on the base, on the side or rear walls, in order to add fixing points with suitable plugs. Take care not to drill the door which contains the mechanism (e.g. to add a handle) because, in the event of damage, the warranty is no longer valid.

The V09 lock coil can remain activated for a maximum of 35 seconds, as intended and allowed by the electronic board supplied with the V09 lock.

Yes, for example, longer fastening screws are supplied with the armoured lock for up and over doors item 8217 to allow application on up and over doors which are up to 40 mm thick.

Yes, in the case of item 809 it is possible to install the security escutcheon even if the lock does not have DIN holes, using the contrast plate supplied and following the instructions provided with the product, which can also be downloaded from the product web page.

Yes, it is possible to adjust the rotating plate located in the security escutcheon (towards the door or towards the outside), according to the protrusion of the cylinder. This adjustment is equal to 5 mm in both directions.

Yes, it is possible to use all the safety cylinders, such as the Palladium, even if they do not have the pin present in the standard cylinders (item 4701) supplied as standard with the adjustable Spranger locking bar.

The technical drawing can be downloaded here.

Yes, it is possible to use the electric lock V09 without electronic board on sliding gates not equipped with automatism; manually moving the gate when opening (after having unlocked the lock with the key) and by closing it simply by pushing.

In order to guarantee the correct operation of the armoured locks for up and over doors series 1.8234 and 1.8252, as well as to protect the safety of users, it is not advisable to remove the internal knob.

If it is a standard Palladium cylinder, you can duplicate the keys in any centre equipped with machines for the duplication of punched keys. If instead it is a Palladium cylinder with a PV protected profile key, it is necessary to go to a Viro Authorized Duplication Centre, showing the coded property card together with an original key and providing personal details. For Palladium cylinders with a patented PB profile key, contact the retailer where the cylinder was purchased and provide the ownership card and an original key, in addition to personal details. The retailer will then request copies directly from Viro.

The protrusion of the cylinder from the outside must be at least 10 mm. and at most 15 mm.

Depending on the thickness of the door, it is possible to use cylinders with an external side measurement of less than or greater than the 57 mm of the standard cylinder. The inner side must be at least 34 mm.

Unlike the mechanical version of the Spranga, on which cams oriented both to the right and to the left of the cylinder axis work, on the electronic Spranga, if a cylinder with an off-centre cam is used, with pull resistant function, it is necessary the use a model with the cam oriented to the left (looking at the cylinder from the inside).

Yes, you can buy additional remote control units.

For activation of the electronic Spranga locking bar it is necessary to use cylinders with a 0° Universal cam or with a 30° DIN cam facing to the left (viewed from the inside). Most of the cylinders, and all the Viro ones, have the cam oriented in this way.

For standard use of the V09 lock the use of the electronic board supplied as standard is envisaged, in case you want to electrically connect the lock without this board, you should contact a specialized technician.

Euro-Pro cylinder keys can be duplicated in all hardware stores which perform the reversible punched key copy service. The code on the ownership card can be used to obtain duplicates, by requesting them from Viro, through a retailer, if all the keys are lost.

The protrusion of the cylinder from the inside must be at least 3 mm.

This pin is only useful to find more easily the correct positioning of the cylinder in the Spranga locking bar.

In order for the device to work properly, it is firstly necessary to check the GSM network coverage in the place where the product will be used. The M.A.C. will only be able to send text messages if there is network coverage.

It is necessary to consult the diagram in the installation notes supplied with the product, which can also be downloaded from the product web page.

The maximum thickness of the up and over door with the standard screws (M6 x 60 mm) supplied with the escutcheon 806, without using the spacer ring, which is only necessary for the slim up and over doors, is 30 mm. For up and over doors with a greater thickness it is necessary to use M6 commercial screws which are longer than the standard 60 mm.

The MAC detects the break-in attempt and starts the alarm procedure. The module takes about 6 seconds to send the attempted break-in message. The time of arrival on the phone is that of a normal text message and depends on the network and the operator used.

Yes, it is possible to adjust the rotating plate located in the security escutcheon (towards the door or towards the outside), according to the protrusion of the cylinder. This adjustment is equal to 5 mm in both directions.

Yes, it detects any movement of the safe and any vibrations on the case and door which are produced in the event of a break-in attempt.

In addition to the thickness of the door and the position of the lock, in order to determine the correct length of the inner / outer sides, it is necessary to take into account the thickness of any trims (for aesthetic purposes) which you intend to install, so that the edge of the cylinder on both sides is as flush as possible and therefore protruding as little as possible.

The device continues cyclically to check the status of the safe. Alarm messages are sent if vibrations are detected and the message "Opening" is sent if the door is opened.

It is not possible to connect to an external siren.

The simple operations for connecting the Viro M.A.S. are shown at this point in the installation video.
